GASKET, SMOOTH RED RBR, 8.000" 300# RF

Ordered as 13880RF125B0800FC, this is a red Red Rubber, Smooth Finish Class 300 ring face Flange Gasket with an 8 inch nominal pipe size, a Class 300 pressure rating, and a thickness of 0.125 inch. The flange gasket compresses between two pipe flanges under bolt load to create a leak-tight joint. Additional detail on this item: NPS, 0.125 THK.

Red Rubber, Smooth Finish is specified here for good conformability on low-pressure flanges, reliable water and air sealing. Expect good resistance to abrasion, water, and mild chemicals. It should not be specified for service in petroleum oils and fuels or ozone and direct sunlight.

It sees regular use in low-pressure air service, general plant maintenance, and water and wastewater.

Order part number 13880RF125B0800FC, sold individually. Review your operating media and conditions against this specification before installation. Not finding the exact configuration you need? APG cross-references from prints, samples and competitor part numbers.
