5/16" GFO GRAPHITE/PTFE PACKING

Ordered as 11800312-10, this is a G.F.O. Packing Compression Packing measuring a 5/16 inch square cross section. The compression packing is cut into rings and stacked in a stuffing box, then compressed by the gland to seal a rotating or reciprocating shaft. Additional detail on this item: 10 LB. Box - Approx. 135 FT.

G.F.O. Packing offers a braided construction that conforms to the stuffing box, controlled leakage that lubricates and cools the shaft. Expect good resistance to process media, elevated temperature and pressure, and shaft wear. Rated for service to approximately 550°F.

You will find this material specified across mixers and rotary equipment, water and process plants, and valves and agitators.

11800312-10 ships individually. Unit weight is approximately 10 lb. As always, verify media compatibility and operating conditions against the requirements of your specific application. For a size or compound outside the standard catalog, APG can quote from a print or sample.
