*3/4" 300/400/600L 316 SS & GRAPHITE RWI

APG stocks the 7GSW6B0075IR, a green 316L Stainless Steel Class 300/400/600 Spiral Wound Gasket supplied with a 0.75 inch nominal pipe size and a Class 300/400/600 pressure rating. A spiral wound gasket alternates metal windings with a soft filler so the gasket recovers elastically through thermal and pressure cycling. The catalog record notes: 316L S.s. Inner Ring - C/s Outer S/w.

As a material, 316L Stainless Steel delivers excellent corrosion resistance in washdown and marine service, dimensional stability under thermal cycling. Expect good resistance to high pressure, chemical attack, and salt water and washdown. It should not be specified for service in chloride stress cracking in some grades or galvanic pairing with dissimilar metals.

Common environments for this compound include pharmaceutical, marine and offshore, and food and beverage processing.

7GSW6B0075IR ships individually. As always, verify media compatibility and operating conditions against the requirements of your specific application.
