*1" 900-1500# 316 SS & GRAPHITE RWI

APG stocks the 7GSW6E0100IR, a green 316L Stainless Steel Class 900/1500 Spiral Wound Gasket built to a 1 inch nominal pipe size and a Class 900/1500 pressure rating. A spiral wound gasket alternates metal windings with a soft filler so the gasket recovers elastically through thermal and pressure cycling. Source specification: 316L S.s. Inner Ring - C/s Outer S/w.

As a material, 316L Stainless Steel offers dimensional stability under thermal cycling and a hygienic, cleanable surface suited to sanitary process lines. This material stands up to elevated temperature, salt water and washdown, and chemical attack. Applications involving chloride stress cracking in some grades or galvanic pairing with dissimilar metals call for a different compound.

Common environments for this compound include chemical transfer, petrochemical, and food and beverage processing.

Reference part number 7GSW6E0100IR when ordering; the item is sold individually. Review your operating media and conditions against this specification before installation. For a size or compound outside the standard catalog, APG can quote from a print or sample.
