*4 1500# 316L SS & GRAFOIL RW S/W GAS

Ordered as 7GSW6F0400, this is a green 316L Stainless Steel Class 1500 Spiral Wound Gasket built to a 4 inch nominal pipe size and a Class 1500 pressure rating. The spiral wound gasket combines metallic strength with a conformable filler for demanding flange service. Additional detail on this item: Special Order.

316L Stainless Steel is known for high mechanical strength and pressure capability, a hygienic, cleanable surface suited to sanitary process lines. This material stands up to high pressure, elevated temperature, and salt water and washdown. It is not the right choice where chloride stress cracking in some grades or galvanic pairing with dissimilar metals are present.

It sees regular use in food and beverage processing, petrochemical, and pharmaceutical.

Reference part number 7GSW6F0400 when ordering; the item is sold individually. Unit weight is approximately 1.06 lb. Application requirements vary, so validate compatibility with your process conditions prior to installation.
