-169 BLACK AFLAS 80D O-RING

Part number A80169 is an AS568-169 black Aflas (TFE/P) 80 Shore A O-Ring built to an inside diameter of 7.487 in (190.17 mm), a cross section of 0.103 in (2.62 mm), and an outside diameter of 7.693 in (195.4 mm). An o-ring creates a positive seal at flange, piston and rod interfaces without added hardware.

Aflas (TFE/P) is specified here for excellent electrical insulating properties and proven performance in aggressive downhole environments. This material stands up to sour gas and hydrogen sulfide, hot water, and high-temperature steam. Service temperature is rated from -25°F (-31.7°C) through 450°F (232.2°C).

Typical settings include downhole tooling, chemical processing, and geothermal equipment.

This item is sold individually under part number A80169. Unit weight is approximately 5.2474 g. Check the compound against your process media, pressure and temperature before committing to a design.
