FASTNER SEAL, STEEL PLATED,

Part number AFS600-0101-9/16 is a black Buna-N (Nitrile) Thread Seal with an inside diameter of 0.563 in (14.29 mm). A thread seal prevents weepage at threaded ports without additional tape or sealant. This item is further identified as Nitrile 70 - 9/16.

Expect good resistance to water, petroleum-based oils, and many alcohols. Buna-N (Nitrile) is widely chosen for low compression set under sustained load, reliable performance in both static and dynamic service. Continuous operating temperature is published at -40°F (-40°C) to 250°F (121.1°C). It is not the right choice where polar solvents or ozone and direct sunlight are present.

Typical settings include agricultural equipment, fluid power, and automotive.

Reference part number AFS600-0101-9/16 when ordering; the item is sold individually. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing.
