-138 BLACK EPDM 70D O-RING

APG stocks the E70138, an AS568-138 black EPDM (EPR) 70 Shore A O-Ring supplied with an inside diameter of 2.112 in (53.64 mm), a cross section of 0.103 in (2.62 mm), and an outside diameter of 2.318 in (58.88 mm). An o-ring seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

Expect good resistance to ozone, UV and weathering, dilute acids and alkalis, and ketones. That behavior comes from the compound itself: EPDM (EPR) is specified for excellent hot water and steam resistance, outstanding weather, ozone and sunlight resistance. Continuous operating temperature is published at -65°F (-53.9°C) to 300°F (148.9°C). It is not the right choice where mineral oil-based lubricants or aromatic hydrocarbons are present.

It sees regular use in HVAC and refrigeration, water and steam systems, and potable water applications.

E70138 ships individually. Unit weight is approximately 1.068 g and nominal inside diameter is listed as 2 1/8 inch. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing.
