-045 BROWN FKM 75D O-RING

This o-ring is supplied in AS568-045 brown Viton® (FKM) 75 Shore A built to an inside diameter of 3.989 in (101.32 mm), a cross section of 0.07 in (1.78 mm), and an outside diameter of 4.129 in (104.88 mm), catalogued under part number VB75045. It delivers dependable bidirectional sealing in a compact groove envelope.

The material holds up against chlorinated solvents, petroleum oils and fuels, and aromatic hydrocarbons. Viton® (FKM) offers long service life in hot, chemically aggressive environments, excellent resistance to compression set and permeation. Published continuous service range is -15°F (-26.1°C) to 400°F (204.4°C). It should not be specified for service in low-molecular-weight organic acids or amines.

You will find this material specified across high-temperature process equipment, aerospace, and chemical processing.

This item is sold individually under part number VB75045. Unit weight is approximately 1.714 g. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing. If you need a size, durometer or compound that is not listed, APG can cross-reference from a print, a sample or a competitor part number.
