2.4MM CS X 4.3MM ID BLACK FKM 75D

Ordered as V2.4X4.3, this is a black Viton® (FKM) 75 Shore A O-Ring with an inside diameter of 4.3 mm (0.169 in), a cross section of 2.4 mm (0.094 in), and an outside diameter of 9.1 mm (0.36 in). The o-ring seats in a machined groove and forms a leak-tight barrier when compressed between two mating surfaces.

Viton® (FKM) is known for excellent resistance to compression set and permeation, outstanding high-temperature capability. Expect good resistance to petroleum oils and fuels, aromatic hydrocarbons, and many acids. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C). It is not the right choice where amines or ketones and esters are present.

Maintenance and OEM teams specify it across chemical processing, aerospace, and oil and gas.

Reference part number V2.4X4.3 when ordering; the item is sold individually. Unit weight is approximately 0.175 g. Check the compound against your process media, pressure and temperature before committing to a design. APG can cross-reference from an existing part number, a drawing or a physical sample if this size is not an exact match.
