GASKET, KLNGR C4433, 4.000 , 150# FF

Ordered as 13C4433FF062A0400, this is a red Klingersil C-4433 Class 150 full face Flange Gasket supplied with a 4 inch nominal pipe size, a Class 150 pressure rating, and a thickness of 0.062 inch. The flange gasket provides a replaceable sealing element at every flanged pipe connection. This item is further identified as NPS,0.062 THK.

The material holds up against a broad range of process chemicals, hydrocarbons, and elevated flange loads. That behavior comes from the compound itself: Klingersil C-4433 delivers consistent thickness and density across the sheet, clean release and easy removal at teardown. Verify compatibility before use with service beyond the published pressure-temperature envelope or strong oxidizing acids in some grades.

Typical settings include pulp and paper, steam and hot water systems, and refining.

Reference part number 13C4433FF062A0400 when ordering; the item is sold individually. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing. APG supports cross-referencing from drawings, samples and competitor numbers when a listed size is not an exact fit.
