APG's Graphite Laminate PSM has a 0.1 mm thick perforated stainless-steel insert. The insert aids material handling properties and increases the blow-out resistance. The insert is mechanically bonded to pure exfoliated graphite and therefore does not rely on adhesive. Stable physical properties over the whole temperature range. This material is suitable for hot water and steam at high temperatures up to 842ºF (450ºC). To prevent the gasket material from sticking to the flange surface (even at high temperatures), the graphite surface can be given a non-stick coating at the customer?s request. With this process, the gasket material?s surface is coated and not impregnated.

Benefits & Features

Features

• Max Pressure: 2900 psi

• Mechanically bonded tanged stainless steel insert

• Temperature Range: -450ºF to 500ºF

• Excellent resistance to chemical attack

• Flexibility makes it easy to hand or die cut and simple to install

• Indefinite shelf life

• Dimensionally stable

Applications

• FDA Applications

• Fragile piping systems

Certifications

• DIN-DVGW

• BAM tested

• TA-Luft (Clean Air)

• FDA conformity (must specify unbranded)

Product Specifications

Typical Values Refer to 1/16'' Thick Material Unless Noted
