-363 RED SILICONE 70D O-RING

Ordered as S70363, this is an AS568-363 red Silicone 70 Shore A O-Ring measuring an inside diameter of 6.475 in (164.47 mm), a cross section of 0.21 in (5.33 mm), and an outside diameter of 6.895 in (175.13 mm). The o-ring provides a reliable static or dynamic seal by deforming into its gland under assembly load.

The material holds up against weathering, dry heat, and many oxidizing chemicals. Silicone delivers flexibility that holds at very low temperatures and excellent electrical insulating properties. Continuous operating temperature is published at -80°F (-62.2°C) to 450°F (232.2°C).

Typical settings include food and beverage processing, electronics and electrical enclosures, and sanitary process lines.

Order part number S70363, sold individually. Unit weight is approximately 16.507 g. Check the compound against your process media, pressure and temperature before committing to a design. For a size or compound outside the standard catalog, APG can quote from a print or sample.
