8-025 BLACK FKM 90D BACK-UP RING

The VBU90025 is an AS568-025 black Viton® (FKM) 90 Shore A Back-Up Ring built to an inside diameter of 1.176 in (29.87 mm), a cross section of 0.07 in (1.78 mm), and an outside diameter of 1.316 in (33.43 mm). This back-up ring extends o-ring service life by supporting the seal against extrusion under high pressure.

As a material, Viton® (FKM) is valued for the industry benchmark where nitrile reaches its thermal limit, excellent resistance to compression set and permeation. Expect good resistance to many acids, aggressive chemicals, and aromatic hydrocarbons. Service temperature is rated from -15°F (-26.1°C) through 400°F (204.4°C).

You will find this material specified across automotive fuel systems, aerospace, and high-temperature process equipment.

Reference part number VBU90025 when ordering; the item is sold individually. Unit weight is approximately 0.3384 g and nominal inside diameter is listed as 1 3/16 inch. Confirm chemical compatibility, pressure and temperature against your own application requirements before installing.
